2JW1001

  • 2JW1001
Teklif Talep Listenize Ekleyin

Ürün Tanımı

2J

Connector Mount,Low Profile,High Efficiency,Ground Plane Dependent

GPS/GLONASS/BeiDou
StandardsGPS/GLONASS/BeiDou/QZSS/Galileo
Frequency1561.098, 1575.42, 1598-1606
VSWR~1.3:1, ~1.3:1, ~1.3:1
Efficiency (%)~70, ~70, ~69
Peak Gain (dBi)~2.9, ~2.8, ~2.9
PolarisationLinear
Max. Input Power (W)25
Impedance (Ohm)50
Radiation PatternOmni-Directional

Ürün Detayları

  • Antenna Type: Harici
  • Bluetooth: -
  • Certificates: -
  • Dimensions (mm): Ø 10 × 71
  • Frequency1: GPS/GLO/BEI/QZSS/Galileo/L1
  • Frequency2: -
  • Frequency3: -
  • Frequency4: -
  • LoRa/Sigfox: -
  • Mounting: Connector Mount
  • Operating Temperature: -20 °C to +65 °C
  • WiFi: -
  • ZigBee: -
